The Leatherwood Camputer ART Principle
Now you can own the same advanced scope technology that made U.S. military snipers in South Vietnam feared by enemy soldiers from the North. Developed by Jim Leatherwood, his now famous ART (Automatic Ranging & Trajectory) scopes made it easier for the military to train qualified long-range snipers by practically eliminating the need to estimate range. Thanks to a simple to read” through the lens” ranging system and fully adjustable external Camputer Cam System, soldiers were able to precisely place shots at ranges far beyond the practical limits of open sights or conventional telescopic sights – without having to guess the range or calculate bullet drop. Over the years, Leatherwood / Hi-Lux Optics Camputer scope system has been steadily improved, and is still in the use by military and law enforcement snipers. Now Leatherwood / Hi-Lux Optics is inducing the new revolutionary ART scope that has the interchangeable Cam system like the M-1000.
Hi Lux Leatherwood 6-24x50mm ART M1200-XLR scope
The 6-24x50mm ART M1200-XLR scope has been re-engineered specifically for the Xtreme Long Range (XLR) shooter and hunter – who need to quickly and accurately place shots of 1000 meters or longer.
Thanks to a larger and completely re-engineered CAMputer system, which can be calibrated for a wider range of calibers, cartridges and loads, shooting different weight bullets at different velocities, the M1200 ART-XLR can now be used with a very high percentage of today’s center-fire rifles – chambered for cartridges from as small as the .223 Remington up to the hard hitting .50 BMG. As long as the shooter knows the bullet ballistic coefficient and the muzzle velocity, this scope can be calibrated for more than 75-percent of today’s most widely used calibers and rifles to automatically keep hits in the kill zone from 300 to 1,200 meters – or within the capability of the bullet and load.
To operate this scope, all the shooter has to do is zoom in on a target of known size until it fits inside the brackets of the ranging reticle…steady the aim…and take the shot. The CAMputer system automatically compensates for both bullet trajectory and range. You don’t even have to know the range – but the reticle includes a ranging scale for those who want to know.
The M1200-XLR features a bigger and brighter 30mm tube, and a sturdier, recoil-proof mount that offers additional external windage adjustment. Precise target style windage and elevation adjustment turrets move bullet impact ¼- inch at 100 yards with each click, while the handy side focus parallax adjustment keeps the target clear and sharp at the longer ranges. Additionally, the M1200-XLR sports an illuminated (available in red or green) etched glass reticle.
Other features include a Fast Focus eye-piece for quick adjustments to eye sight, Tri-Center coil spring tension on the erector tube for positive click adjustment, and a tough PermaCoat finish that makes the scope resistant to scuffs and normal wear. All lenses are fully multi-coated with our proprietary DiamondTuff14 coating for optimum light transmission. The Leatherwood CAMPUTER scope system is the most advanced ART (Automatic Ranging & Trajectory) system. This ART System is in worldwide use and its history exemplifies our commitment to building only the best rifle scopes. Power 6X-24X , Object lens 50, Exit Pupil Range 8.5 - 2 , EYE Relief 3.25" , Length 15.5" , Short Reticle Ranging XLR Reticle , Elevation Adjustment 1/4 (MOA) , Short Feature Auto Ranging Trajectory, XLR reticle , FOV 12' - 4'' , Coating Diamond Tuff14
Features:
1. Auto-Ranging Trajectory - Mechanical “Camputer” system moves scope up and down to automatically compensate for bullet drop hold over. 2. Quick Eyepiece Focus - Quick focus adjustment on eyepiece so the shooter can focus more on hitting the target, rather than the clarity of the eyepiece. 3. Multi-Coated Lenses - All exterior air-glass lenses are treated with DiamondTuff14™ to ensure optimal light transmission for more visibility in low light situations. 4. Nitrogen Gas Purged - All scopes are purged with nitrogen gas to ensure they remain fogproof for wide range of temperatures. 5. Waterproof - Rubber O-ring prevents moisture, dust and debris particles from penetrating the scope. 6. Second Focal Plane - The reticle stays the same size even when adjusting the magnification of the scope. Allows shooter to easily estimate range. 7. Perma-Coat - Soft-luster blue-black finish coat is applied to the body of the scope. Ensures coat is wear resistant and protects exterior from scratches. 8. “ZRO-LOK” System - The zero-locking system allows the scope’s alignment to be locked in place once the scope is sighted in. Once the scope is locked in, this system offers minimal adjustment for slight tweaking of shot placement. 9. Tri-Center Spring Tension - Offers positive click adjustment tracking for windage and elevation. 10. One piece Aluminum Tube - Single piece 30mm rifle scope tube construction allows for optimal waterproofing and tensile strength design. 11. XLR Ranging Illuminated Reticle in Red or Green - Allows for easy range finding by milling or framing targets. 12. External Windage Adjustment - The M1200 ART scope mount has built-in elevation adjustment.
Hi Lux Leatherwood 6-24x50mm ART M1200-XLR scope $560.00
Leatherwood Camputer M-1000 ART Scope
All the shooter has to do is to place the reticle on the target, zoom in to “FRAME” an area of known size (i.e. the 18" height of a buck's chest cavity), AIM, and squeeze the trigger to “SHOOT”. It all takes less than 5 seconds, and the shooter's eye never leaves the scope! When the shooter frames an 18” or 1 meter target using the brackets on the reticle, the scope will automatically range the target and compensate for bullet trajectory for distances of 250 to 1,000 meters. This means no “holdover” or guesswork.
The cam of this new generation 2.5-10x44mm ART (Auto Ranging Trajectory) system, which was invented and designed by Jim Leatherwood for military snipers in Vietnam during the 1960s, has been redesigned for today's sportsmen. New, interchangeable modular cams make it simpler than ever to precisely calibrate this system for just about any center-fire rifle cartridge -from .223 to .50 BMG. The shooter can switch cams in a minute or less! Also, the new design permits the cam…calibration ring…and range ring to be used or set independently and more precisely. Easy access locking screws make changes quick and easy.
Other features, which make this the greatest ART model ever, include:
1. Multi-Dial rings that permit this scope to be pre-programmed for up to 4 different zeros or multiple guns. 2. New cam roller that permits easier operation of the ART system. Interchangeable size rollers for more precise calibration . 3. New mount with built in windage adjustment. 4. Quick focus eyepiece that allows easy multi-shooter use. 5. A No-Math Mil Dot reticle for easier ranging. You can turn this reticle to a true Mil Dot Reticle at 10 X.
ART2510X44 Leatherwood 2.5-10x44 Camputer ART M-1000 Rifle Scope Specifications Weight (oz): 25.2
No Math Mil-Dot Length (in): 13.2 Eye Relief (in): 3 Field of View @ 100yds (ft): 47.2 - 11.9 Exit Pupil (mm): 10.2 - 4 MOA: 1/4 Lens Coating: DiamondTuFF 14 Warranty: Limited Lifetime $436.00
eatherwood m1000
m1a leatherwood m1200
leatherwood lart624x50tak
leatherwood 6-24x50 m-1200
leatherwood art scope reviews
leatherwood art m-1200
leatherwood camputer
auto range scope
Leatherwood Uni-Dial Series
In the past there were two options for long range shooting: shoot a specific load or tape a chart of "computes" to the rifle stock. The Uni-Dial is designed to solve the problem.
By using a series of ten moveable indicators or flags, the shooter can set the range zero points himself. The dial is calibrated in minutes so that the Flags can be set according to the ballistic data. Once set, the flags are locked in place and the dial is operated in a conventional manner. The vertical dial has 1/2 minute click adjustment and windage dial has 1/4 minute clicks. Both adjustments have a tope to prevent the shooter from getting "lost" as to where his zero is. But both adjustments can be unlocked from the stops to permits zeroing.
The flags are numbered from 1 to 10. All allow the shooter to pre-program elevation and windage for up to 10 different ranges, or with different loads - and each can be locked in place and returned to within seconds. The total minutes of elevation change for is about 60 MOA. There are about 20 minutes for initial zeroing. One full-turn for the change of elevation is 40 MOA. The Leatherwood / Hi-Lux Uni-Dial scopes now have all improved with a wider range of variable magnifications. The 3-12x, 4-16x, 6-24x and 7-30x in the Leatherwood / Hi-Lux A.T.R. Uni-Dial Series are featured with the handy Top-Angle Focus. All these models come with the enlarged erector/turret housing to make these the brightest 1" diameter scopes available today. They all come with the extended sunshade.
UD2510X44MD New Leatherwood 2.5-10x44 Uni-Dial Rifle Scope Specifications Weight (oz): 15.3
Mil-Dot Length (in): 13.2 Eye Relief (in): 3 Field of View @ 100yds (ft): 47.2 - 11.9 Exit Pupil (mm): 10.2 - 4 MOA: 1/2 (Elevation) 1/4 (Windage) Lens Coating: DiamondTuFF 14 Warranty: Limited Lifetime $284.00 with free shipping
UD312X50MD New Leatherwood 3-12x50 Uni-Dial Rifle Scope Specifications Weight (oz): 25.6
Mil-Dot Length (in): 13.6 Eye Relief (in): 3 Field of View @ 100yds (ft): 40.3 - 10.2 Exit Pupil (mm): 10 - 3.3 MOA: 1/2 (Elevation) 1/4 (Windage) Lens Coating: DiamondTuFF 14 Warranty: Limited Lifetime $348.00 with free shipping
UD416X50MD New Leatherwood 4-16x50 Uni-Dial Rifle Scope Specifications Weight (oz): 26.8
Mil-Dot Length (in): 14.1 Eye Relief (in): 3.25 Field of View @ 100yds (ft): 24.1 - 6.3 Exit Pupil (mm): 10 - 3 MOA: 1/2 (Elevation) 1/4 (Windage) Lens Coating: DiamondTuFF 14 Warranty: Limited Lifetime
UD416X50MD $365.00 with free shipping
UD730X50MD New Leatherwood 7-30x50 Uni-Dial Rifle Scope Specifications Weight (oz): 29.7
Mil-Dot Length (in): 17.2 Eye Relief (in): 3.3 Field of View @ 100yds (ft): 10.6 - 3.5 Exit Pupil (mm): 6.9 - 2.3 MOA: 1/2 (Elevation) 1/4 (Windage) Lens Coating: DiamondTuFF 14 Warranty: Limited Lifetime UD730X50MD $449.00 with free shipping
MD39X40MD New Leatherwood 3-9x40 Multi-Dial Rifle Scope Specifications Weight (oz): 18.7
No Math Mil-Dot Length (in): 12.5 Eye Relief (in): 3.25 Field of View @ 100yds (ft): 37.7 - 12.6 Exit Pupil (mm): 13.3 - 4.4 MOA: 1/2 (Elevation) 1/4 (Windage) Lens Coating: DiamondTuFF 14 Warranty: Limited Lifetime MD39X40MD $198.00 with free shipping
TBML39X40 New Leatherwood 3-9x40 Toby Bridges Muzzleloader Scope Specifications Weight (oz): 15.8
TBML (BDC Style Recle) Length (in): 12.5 Eye Relief (in): 3.25 Field of View @ 100yds (ft): 39 - 13 Exit Pupil (mm): 13.3 - 4.4 MOA: 1/4 Lens Coating: DiamondTuFF 14 Warranty: Limited Lifetime TBML39X40 $158.00
The Leatherwood ATR Top-Angle Professional 30mm Series is made up of higher magnification 3-12x to 8-32x models, and each features our own invented Top-Angle parallax adjustment and positive Fast Focus large diameter ocular lens. No short-cuts are taken to produce these scopes. All glass lenses are meticulously polished to photographic quality for exceptional clarity and light gathering capability, even during those critical low light hunting conditions at daybreak and dusk.
The rigid aluminum scope tube is finished with Leatherwood / Hi-Lux PermaCoat soft luster blue-black finish that’s practically impervious to wear, insuring this scope will maintain its good looks through years of hard service. Internally, Leatherwood / Hi-Lux Optics ATR Top-Angle Professional 30mm Series scopes incorporate all the latest scope manufacturing technology, and the turret adjustments are positive and precise.
You can pay more, a lot more, but you simply cannot buy a brighter, more precise or tougher built 30mm scope! If you're looking to take your shooting to the professional level, you need one of these scopes on your rifle. Anything else is second best. The Top-Angle Focus Adjustment Patent is applied and Pending.
TP730X50MD Leatherwood / Hi-Lux Optics ATR Top Angle Professional 7 - 30x50 30mm Mil Dot Reticle:
Specifications Power: 7X-30X Obj.Lens Dia-mm: 50 F.O.V. @ 100Yds (Feet): 10.6-3.5 Exit Pupil Range in Variable (mm): 6.9-2.3 Eye Relief (Inches): 3.3 Length (Inch): 17.2 Weight (Oz): 29.8 Coating: Diamond TuFF14 Reticle: Mil-Dot Elev.MOA: 1/4 Wind.MOA: 1/4 Features: 30mm Tube, Top Angle, Mil Dot
TP730X50MD $426.00 with free shipping
TP730X50MDIR Leatherwood / Hi-Lux Optics ATR Top Angle Professional 7 - 30x50 30mm IR w/ Illuminated Mil Dot Reticle: Power: 7X-30X Obj.Lens Dia-mm: 50 F.O.V. @ 100Yds (Feet): 10.6-3.5 Exit Pupil Range in Variable (mm): 6.9-2.3 Eye Relief (Inches): 3.3 Length (Inch): 17.2 Weight (Oz): 30.1 Coating: Diamond TuFF14 Reticle: Mil-Dot Elev.MOA: 1/4 Wind.MOA: 1/4 TP730X50MDIR $474.00 with free shipping
TP416X50MD Leatherwood / Hi-Lux Optics ATR Top Angle Professional 4 - 16x50 30mm Mil Dot Reticle:
Specifications Power: 4X-16X Obj.Lens Dia-mm: 50 F.O.V. @ 100Yds (Feet): 24.1-6.3 Exit Pupil Range in Variable (mm): 10-3 Eye Relief (Inches): 3.25 Length (Inch): 14.1 Weight (Oz): 26.5 Coating: Diamond TuFF14 Reticle: Mil-Dot Elev.MOA: 1/4 Wind.MOA: 1/4 Features: 30mm Tube, Top Angle, Mil Dot
TP416X50MD $329.00 with free shipping
